X99 Chipset Motherboard with LGA2011-3 Socket and Four-Channel DDR4 Memory Support

This X99 series motherboard delivers a feature-rich platform for high-performance computing applications, built around Intel's enthusiast-grade chipset architecture. Designed to accommodate demanding workloads from content creation to gaming, the board supports both consumer-grade Intel Core i7 processors and professional Xeon E5 v3 series CPUs through its LGA2011-3 socket interface. With comprehensive connectivity options including dual PCI-E x16 slots for graphics expansion and eight SATA 3.0 ports for storage arrays, this motherboard provides substantial expansion capability within the standard ATX form factor. The integrated 7.1 channel audio solution eliminates the need for discrete sound cards in most scenarios, while RTL8111H gigabit networking ensures reliable high-speed data transfer for both local network access and internet connectivity.

Processor and Memory Specifications

The motherboard's foundation centres on the LGA2011-3 socket, designed specifically for high-core-count processors requiring substantial thermal management solutions. This platform supports the full range of compatible CPUs, providing users with flexibility in system configuration according to performance requirements and budget considerations.

CPU Compatibility

The LGA2011-3 socket accommodates Intel Core i7 processors from the 5000 series including the 5820K and 5960X models, alongside Xeon E5 v3 series server processors. Important compatibility consideration: when using Core i7 consumer processors, standard desktop memory modules must be installed rather than registered ECC server memory. The socket's 2011 pins provide the necessary connections for these processors' high memory bandwidth requirements and PCIe lane configurations.

Memory Configuration

Four DDR4 DIMM slots arranged in a quad-channel configuration support memory speeds up to 2400MHz or 2333MHz, with capacity reaching 32GB per slot for maximum system memory of 128GB. This arrangement provides substantially higher memory bandwidth compared to dual-channel systems, particularly beneficial for memory-intensive applications like video editing, 3D rendering, and scientific simulations. The motherboard accepts both standard unbuffered desktop memory and registered ECC modules when paired with compatible Xeon processors.

Power Delivery

Power input comes through standard 24-pin ATX and 8-pin EPS12V connectors, with the system capable of operating with only the 4-pin section of the CPU power connector when using lower-power configurations. Four distinct power phases manage voltage regulation to the CPU and memory subsystems, helping maintain stability during intensive computing tasks and potential overclocking scenarios.

Expansion and Storage Options

Beyond core processor and memory support, the motherboard provides substantial expansion capability through multiple PCIe slots and comprehensive storage interfaces. This allows users to configure systems tailored to specific workloads, whether focusing on graphics performance, storage capacity, or specialised peripheral connectivity.

PCIe Expansion Slots

Two PCI-E x16 slots accommodate high-performance graphics cards in either single or dual configurations, with potential for SLI or CrossFire multi-GPU setups when supported by appropriate bridge connectors. Three additional PCI-E x1 slots provide expansion for sound cards, network adapters, USB controllers, or other specialised interface cards. The PCIe implementation supports both current-generation and legacy expansion cards through backward compatibility.

Storage Interfaces

Eight SATA 3.0 ports deliver 6Gb/s connectivity for hard disk drives, solid-state drives, and optical drives, supporting various RAID configurations for data redundancy or performance enhancement. The M.2 PCIe NVMe interface enables installation of next-generation solid-state drives that communicate directly through PCIe lanes rather than the SATA interface, substantially reducing latency and increasing sequential transfer speeds for operating systems and frequently accessed applications.

Additional Connectivity

Front panel headers include two USB 2.0 ports and two USB 3.0 interfaces for case-mounted connectivity. The integrated I/O panel provides four USB 3.0 ports and four USB 2.0 ports alongside PS/2 keyboard/mouse combination port for legacy peripheral support. Wireless networking capability comes through an optional WiFi module installed via the dedicated interface, while eight multi-colour LED audio path lighting adds visual indication of audio signal routing through different channels.

Integrated Features and System Management

The motherboard incorporates several integrated components that reduce the need for additional expansion cards while providing essential system management capabilities. These features combine to create a comprehensive platform requiring minimal additional components for fully functional operation.

Audio and Networking

Integrated 7.1 channel audio delivers quality sound reproduction through standard 3.5mm audio jacks, supporting surround sound speaker configurations for gaming, movies, and music production. The Realtek RTL8111H gigabit network controller provides reliable wired networking with hardware acceleration for reduced CPU utilisation during network-intensive tasks. Both audio and network solutions benefit from dedicated PCB separation from main digital circuits to reduce electromagnetic interference.

Diagnostic and Monitoring

A digital fault diagnosis display provides two-digit POST code readout during system startup, helping identify specific hardware issues during the boot process. An integrated buzzer provides audible confirmation of successful POST completion or indicates fault conditions through specific beep patterns. These diagnostic tools simplify troubleshooting when components fail or experience compatibility issues.

Warranty and Support

The motherboard comes with a three-year limited warranty comprising first-year free repair or replacement and two subsequent years of cost-based maintenance services. Manufacturers continuously optimise and upgrade production components, which may result in slight variations in slot colours or minor specification adjustments between production batches. Users should consult manufacturer documentation for the most current compatibility information and driver updates.
